BSP (British Standard Pipe) male fittings with an ED-ring represent a vital component within the realm of fluid and gas conveyance systems. The BSP threading standard, originating in the United Kingdom, has become globally recognized for its reliability and consistency in hydraulic and pneumatic applications.
What sets BSP male fittings with an ED-ring apart is the integration of an ED-ring, a crucial sealing mechanism. The ED-ring, also known as an elastomer double ring or O-ring, plays a pivotal role in ensuring a tight and dependable seal. This feature is particularly essential in high-pressure systems where maintaining an airtight or watertight connection is paramount for safety, efficiency, and durability.
The inclusion of the ED-ring provides an added layer of security against leaks, enhancing the overall performance and longevity of the fluid or gas handling system. As industries continue to evolve and demand higher standards of precision and reliability, BSP male fittings with an ED-ring stand as a testament to engineering innovation and steadfast commitment to achieving leak-free and efficient operations.
PART NO. | Thread | WINNER PART NO. | Description | |
1 | 2 | |||
GE 06L-1/8"BSP ED | M12×1.5 | G1/8"-19 | 1CB-12-02WD |  |
GE 08L-1/4"BSP ED | M14×1.5 | G1/4"-19 | 1CB-14-04WD | |
GE 10L-1/4"BSP ED | M16×1.5 | G1/4" 19 | 1CB-16-04WD | |
GE 12L-1/4"BSP ED | M18×1.5 | G1/4"-19 | 1CB-18-04WD | |
GE 08L-3/8"BSP ED | M14×1.5 | G3/8"-19 | 1CB-14-06WD | |
GE 10L-3/8"BSP ED | M16×1.5 | G3/8"-19 | 1CB-16-06WD | |
GE 12L-3/8"BSP ED | M18×1.5 | G3/8“-19 | 1CB-18-06WD | |
GE 15L-3/8"BSP ED | M22×1.5 | G3/8"-19 | 1CB-22-06WD | |
GE 12L-1/2"BSP ED | M18×1.5 | G1/2"-14 | 1CB-18-08WD | |
GE 15L-1/2"BSP ED | M22×1.5 | G1/2"-14 | 1CB-22-08WD | |
GE 18L-1/2"BSP ED | M26×1.5 | G1/2"-14 | 1CB-26-08WD | |
GE 18L-3/4"BSP ED | M26×1.5 | G3/4"-14 | 1CB-26-12WD | |
GE 22L-3/4"BSP ED | M30×2.0 | G3/4"-14 | 1CB-30-12WD | |
GE 22L-1"BSP ED | M30×2.0 | G1"-11 | 1CB-30-16WD | |
GE 28L-1"BSP ED | M36×2.0 | G1"-11 | 1CB-36-16WD | |
GE 35L-1"BSP ED | M45×2.0 | G1"-11 | 1CB-45-16WD | |
GE 35L-1.1/4"BSP ED | M45×2.0 | G1.1/4"-11 | 1CB-45-20WD | |
GE 42L-1.1/2"BSP ED | M52×2.0 | G1.1/2"-11 | 1CB-52-24WD | |
GE 06S-1/4"BSP ED | M14×1.5 | G1/4"-19 | 1DB-14-04WD | |
GE 08S-1/4"BSP ED | M16×1.5 | G1/4"-19 | 1DB-16-04WD | |
GE 10S-1/4"BSP ED | M18×1.5 | G1/4" 19 | 1DB-18-04WD | |
GE 10S-3/8"BSP ED | M18×1.5 | G3/8"-19 | 1DB-18-06WD | |
GE 12S-3/8"BSP ED | M20×1.5 | G3/8"-19 | 1DB-20-06WD | |
GE 14S-3/8"BSP ED | M22×1.5 | G3/8“-19 | 1DB-22-06WD | |
GE 14S-1/2'BSP ED | M22×1.5 | G1/2"-14 | 1DB-22-08WD | |
GE 16S-1/2"BSP ED | M24×1.5 | G1/2"-14 | 1DB-24-08WD | |
GE 20S-1/2"BSP ED | M30×2.0 | G1/2"-14 | 1DB-30-08WD | |
GE 20S-3/4"BSP ED | M30×2.0 | G3/4"-14 | 1DB-30-12WD | |
GE 25S-3/4"BSP ED | M36×2.0 | G3/4"-14 | 1DB-36-12WD | |
GE 25S-1"BSP ED | M36×2.0 | G1"-11 | 1DB-36-16WD | |
GE 30S-1"BSP ED | M42×2.0 | G1"-11 | 1DB-42-16WD | |
GE 30S-1.1/4"BSP ED | M42×2.0 | G1.1/4"-11 | 1DB-42-20WD | |
GE 38S-1.1/2"BSP ED | M52×2.0 | G1.1/2"-11 | 1DB-52-24WD | |
Note: The above code includes adapters, if you need a complete set, please add "RN", such as "GE 06L-1/8"BSP ED/RN".
