The JIC Male 37° Cone/BSPT Male fitting is a crucial component in fluid and hydraulic systems, renowned for its reliability, versatility, and efficiency. This fitting is a cornerstone in hydraulic engineering and plays a pivotal role in facilitating seamless connections within hydraulic systems.
The JIC Male 37° Cone/BSPT Male fitting is specifically designed to connect hydraulic hoses or tubes in a secure and leak-free manner. The 37° cone angle on the male fitting ensures a robust seal when connected with a corresponding female fitting, guaranteeing a tight connection capable of withstanding high-pressure applications. This design allows for a metal-to-metal seal, enhancing its durability and resistance to wear and tear over extended periods of use.
In addition to its sealing capabilities, the BSPT (British Standard Pipe Taper) threading on the male end of the fitting ensures a secure fit within the hydraulic system. The tapering design provides a reliable seal and prevents leakage, making it suitable for various hydraulic applications across different industries.
PART NO. | Thread | WINNER PART NO. | Description | |
1 | 2 | |||
ADGA-07-02 | 7/16"-20 | R1/8"-28 | 1JT-04-02SP |
|
ADGA-07-04 | 7/16"-20 | R1/4"-19 | 1JT-04SP | |
ADGA-07-06 | 7/16"-20 | R3/8"-19 | 1JT-04-06SP | |
ADGA-08-02 | 1/2"-20 | R1/8"-28 | 1JT-05-02SP | |
ADGA-08-04 | 1/2"-20 | R1/4"-19 | 1JT-05-04SP | |
ADGA-08-06 | 1/2"-20 | R3/8"-19 | 1JT-05-06SP | |
ADGA-09-02 | 9/16"-18 | R1/8"-28 | 1JT-06-02SP | |
ADGA-09-04 | 9/16"-18 | R1/4"-19 | 1JT-06-04SP | |
ADGA-09-06 | 9/16"-18 | R3/8"-19 | 1JT-06SP | |
ADGA-09-08 | 9/16"-18 | R1/2"-14 | 1JT-06-08SP | |
ADGA-12-06 | 3/4"-16 | R3/8"-19 | 1JT-08-06SP | |
ADGA-12-08 | 3/4"-16 | R1/2"-14 | 1JT-08SP | |
ADGA-12-12 | 3/4"-16 | R3/4"-14 | 1JT-08-12SP | |
ADGA-14-06 | 7/8"-14 | R3/8"-19 | 1JT-10-06SP | |
ADGA-14-08 | 7/8"-14 | R1/2"-14 | 1JT-10-08SP | |
ADGA-14-12 | 7/8"-14 | R3/4"-14 | 1JT-10-12SP | |
ADGA-17-08 | 1.1/16"-12 | R1/2"-14 | 1JT-12-08SP | |
ADGA-17-12 | 1.1/16"-12 | R3/4"-14 | 1JT-12SP | |
ADGA-17-16 | 1.1/16"-12 | R1"-11 | 1JT-12-16SP | |
ADGA-21-12 | 1.5/16"-12 | R3/4"-14 | 1JT-16-12SP | |
ADGA-21-16 | 1.5/16"-12 | R1"-11 | 1JT-16SP | |
ADGA-21-20 | 1.5/16"-12 | R1.1/4"-11 | 1JT-16-20SP | |
ADGA-26-16 | 1.5/8"-12 | R1"-11 | 1JT-20-16SP | |
ADGA-26-20 | 1.5/8"-12 | R1.1/4"-11 | 1JT-20SP | |
ADGA-26-24 | 1.5/8"-12 | R1.1/2"-11 | 1JT-20-24SP | |
ADGA-30-20 | 1.7/8"-12 | R1.1/4"-11 | 1JT-24-20SP | |
ADGA-30-24 | 1.7/8"-12 | R1.1/2"-11 | 1JT-24SP | |
ADGA-30-32 | 1.7/8"-12 | R2"-11 | 1JT-24-32SP | |
ADGA-40-24 | 2.1/2"-12 | R1.1/2"-11 | 1JT-32-24SP | |
ADGA-40-32 | 2.1/2"-12 | R2"-11 | 1JT-32SP | |
