When your operations demand absolute strength and relentless durability, turn to our Spiral Wire Hose series. Engineered for the most extreme heavy-duty hydraulic applications, this comprehensive range of spiral wire hose is built to withstand ultra-high pressure, high impulse cycles, and the toughest environmental challenges.
Our spiral wire reinforcement technology provides superior burst pressure resistance, ensuring maximum safety and uptime in mining, construction, industrial, and offshore applications.
Extreme Pressure Capability of the Wire Spiral Hose: Up to 6,090 PSI constant pressure.
Exceeds Major Global Standards: SAE J343 & EN856.
Optimized for High Impulse Cycles: Maximizes service life under dynamic conditions.
Full Range of Sizes: From 3/8" to 2".
High impulse applications (exceeds 1,000,000 cycles) of this hydraulic spiral hose.
Abrasion resistant cover (optional) with 30 times or 300 times stronger abrasion resistant available.
| WP (PSI) | SPECIFICATION | GRENBERT MODEL | ID RANGE | |
| 6090 | SAE 100R15 | -40°C to 121°C | 8500 | 3/8" to 2" |
| 5070 | SAE 100R13 | -40°C to 121°C | 8300 | 3/8" to 2" |
| 2530 - 4060 | SAE 100R12 | -40°C to 121°C | 8200 | 3/8" to 2" |
| 3620 - 6520 | EN856 4SH | -40°C to 121°C | 8900 | 5/8" to 2" |
| 4640 - 6520 | EN856 4SP | -40°C to 121°C | 8000 | 3/8" to 1" |
