Engineered for reliability beyond standard hydraulic oil, the 6300, 6600, and associated series are your trusted solution for conveying a wide range of media—from anti-freeze and water to lubricants and return-line fluids. Built to exceed stringent SAE specifications, these hoses are designed to deliver consistent performance in medium to low-pressure applications, even under high operating temperatures.
Broad Media Compatibility: Reliably transmits hydraulic oil, anti-freeze, water, lubricants, and air.
Superior High-Temperature Performance: Most series offer HT (High-Temp) variants, ensuring stable operation in demanding thermal environments.
Comprehensive Pressure Range: Covers medium to low-pressure applications, including dedicated return-line solutions.
Global Standard Certification: Complies with and exceeds international standards including SAE 100R3, 100R4, 100R5, and 100R6.
| WP (PSI) | SPECIFICATION | GRENBERT MODEL | ID RANGE | PAGE | |
| 350 - 1260 | SAE 100R3 | -40°C to 100°C | 6300 | 1/4" to 1-1/2" | B27 |
| 350 - 1260 | SAE 100R3 (HI-TEMP) | -40°C to 135°C | 6300HT | 1/4" to 1-1/2" | B28 |
| 250 - 400 | SAE 100R6 | -40°C to 100°C | 6600 | 1/4" to 1" | B29 |
| 250 - 400 | SAE 100R6 (HI-TEMP) | -40°C to 135°C | 6600HT | 1/4" to 1" | B30 |
| 60 - 300 | SAE 100R4 | -40°C to 100°C | 6400 | 3/4" to 3" | B31 |
| 60 - 300 | SAE 100R4 (HI-TEMP) | -40°C to 135°C | 6400HT | 3/4" to 3" | B32 |
| 300 | PUSH LOCK HOSE | -40°C to 100°C | 6700 | 1/4" to 3/4" | B33 |
| 300 | PUSH LOCK HOSE | -40°C to 100°C | 6700HT | 1/4" to 3/4" | B34 |
| 350 - 3000 | SAE 100R5 | -40°C to 100°C | 5500 | 3/16" to 2- | B35 |
| 350 - 3000 | SAE 100R5 (HI-TEMP) | -40°C to 150°C | 5500HT | 3/16" to 2- | B36 |
